Panjit MMBT3904 Transistor 40V 200mA SOT-23-3

Description

Panjit MMBT3904 Transistor GP BJT NPN 40V 0.2A 3-Pin SOT-23 T/R , NPN GENERAL PURPOSE SWITCHING TRANSISTOR

Product Category: Bipolar Transistors – BJT
RoHS: RoHS Compliant Details
Configuration: Single
Transistor Polarity: NPN
Collector- Base Voltage VCBO: 60 V
Collector- Emitter Voltage VCEO Max: 40 V
Emitter- Base Voltage VEBO: 6 V
Collector-Emitter Saturation Voltage: 0.3 V
Maximum DC Collector Current: 0.2 A
Gain Bandwidth Product fT: 300 MHz
Maximum Operating Temperature: + 150 C
Mounting Style: SMD/SMT
Package / Case: SOT-23

• NPN epitaxial silicon, planar design

• Transition frequency fT>300MHz @ IC=10mAdc,

• Lead free in compliance with EU RoHS 2011/65/EU directive

• Green molding compound as per IEC61249 Std. . (Halogen Free)

The MMBT3904 from Fairchild is a surface mount, NPN general purpose amplifier in SOT-23 package. This device is suitable for general purpose amplification and switching applications.

Collector to emitter voltage (Vce) of 40V
Collector to emitter saturation voltage of 300mV at 50mA collector current
Power dissipation of 350mW
DC collector current of 200mA
DC current gain of 30 at Ic=100mA
Operating junction temperature range from -55°C to 150°C

Manufacturer Part Number: MMBT3904

Manufacturer: Panjit

Datasheet: MMBT3904.pdf
