HSEUIREG07201.18T Camtec Programmable Power Supply 18V 720W

HSEUIREG07201.18T Camtec Programmable Power Supply 18V 720W

$0.00

HSEUIREG07201.18T Camtec Bench Top Power Supply PSU (Ajustable) 0 – 18V DC 0-40A 720W DIN rails RoHS

SKU: HSEUIREG07201.18T Category: Tag:

Description

HSEUIREG07201.18T Camtec Bench Top Power Supply PSU (adjustable voltage) 0 – 18 V DC 0 – 40 A 720 W No. of outputs 1 DIN rails , Laboratory power supply for DIN rails 115/230 V/720W, voltage and current programmable from 0 – 18 V/0 – 40 A
Technical data

TypeHSEUIreg07201.18T
No. of outputs1
Power
720 W
Weight2900 g
Output current 1040 A
Height130 mm
Length114.5 mm
Width200 mm
Calibrated to
Manufacturer’s standards (no certificate)
MTBF400000 hr
The HSEUreg power supplies have complex active filter with suppressor diodes, X2 capacitors and varistors for protection against input transients. The circuit design has been besoderer value on noise immunity and safety. The switching power supplies are in accordance with the requirements of EN 60950-1 and EMC compliance EN55022 Class B.

ModelArt. No.StockTypeInput voltage (min.)Input voltage (max.)Output voltagePowerOutput Current (max.)HeightWidthDepthWeight
HSEUIreg07201.18TCT1060 DIN rail90 V AC265 V AC18 V DC720 W40 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.30TCT1092 DIN rail90 V AC265 V AC30 V DC720 W30 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.50TCT1093 DIN rail90 V AC265 V AC50 V DC720 W18 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.90TCT1085 DIN rail90 V AC265 V AC90 V DC720 W10 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.130TCT1086 DIN rail90 V AC265 V AC130 V DC720 W7 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.180TCT1104 DIN rail90 V AC265 V AC180 V DC720 W5 A130 mm200 mm114.5 mm3 kg
HSEUIreg07201.240TCT1144 DIN rail90 V AC265 V AC240 V DC720 W3,80 A130 mm200 mm114.5 mm3 kg

Manufacturer Part Number: HSEUIREG07201.18T

Manufacturer: Camtec

Datasheet: Camtec/hseuireg0720118t.pdf
